Mecer 850VA Line Interactive UPS (ME-850-VU)

Mecer 850VA Line Interactive UPS (ME-850-VU) from the leading mecer 850VA UPS authorized dealer, buy online  850VA Line Interactive UPS (ME-850-VU).

Mecer 850VA Off-Line UPS (ME-850-VU) – Capacity: 850VA / 480W, Input: 220Vac-240Vac, 60/50Hz, Connectivity, power output: 1 x SA 3-Pin Plug Sockets, 2 x IEC C13 Female Sockets, Includes AVR, Monitoring Software, Built-in Surge Protection, Black Colour – Power Cable Not Included.

Mecer 850VA Line Interactive UPS can charge up to 90% in battery capacity within a 4-6 hour period. This UPS provides built-in protection against Power overloads, discharge and overcharging of the device

Mecer 850VA Line Interactive UPS specifications

• Power Capacity: 850VA / 480W
• Input Voltage: 220VAC
• Output Voltage: 230VAC ± 10%
• Input Frequency: 50/60Hz ± 5Hz
• Output Frequency: 50/60Hz ± 1Hz (Battery Mode)
• Transfer Time: <10ms (Typical)
• Battery Type: Sealed lead-acid maintenance-free battery
• Battery Voltage: 12VDC
• Backup Time: Approximately 5-20 minutes (depending on load)
• Recharge Time: 4-6 hours to 90% capacity
• Number of Outlets: 4EC C13 outlets
• Surge Protection: Yes
• Communication Interface: USB
• Software: PowerMaster UPS monitoring software
• Audible Alarm: Battery mode, low battery, overload, fault
• Dimensions: 100mm x 146mm x 320mm (W x H x D)
• Weight: 4.5 kg (9.9 lbs)

• Capacity 850 VA / 480 W
• Input Voltage 110/120 VAC or 220/230/240 VAC
• Voltage Range 81-145 VAC  /  162-290 VAC
• Frequency Range 60-50 Hz (auto sensing)
• Output AC Voltage Regulation (Batt. Mode) ±10%
• Frequency Range (Batt. Mode) 60 Hz or 50 Hz  ±1 Hz
• Transfer Time Typical 2-6ms, 10ms max
• Waveform (Batt. Mode) Simulated Sine Wave
• Battery Battery Type & Number 12 V/9 AH x 1
• Typical Recharge Time 4-6 hours recover to 90% capacity
• Indicators AC Mode Green Lighting
• Battery Mode Yellow Flashing
• Fault Red Flashing
• Protection Full Protection Overload, discharge and over charge protection
• Alarm Battery Mode Sounding every 10 seconds
• Low Battery Sounding every second
• Overload Sounding every 0.5 seconds
• Battery Replacement Alarm Sounding every 2 seconds
• Fault Continuously Sounding
• Physical Dimensions, D X W X H(mm) 287 x 100 x 142
• Net Weight (kgs) 4.9
• Operating Environment Humidity 0-90 % RH @ 0- 40° (non-condensing)
• Noise Level Less than 40dB
• Management Optional USB/RS-232 Port Supports Windows® 2000/2003/XP/Vista/2008/7, Linux, Unix and MAC

Conclusion

The Mecer ME-850-VU is an 850VA Line Interactive UPS designed to provide reliable power protection for your electronic devices. With a power capacity of 850VA or 480W, it offers sufficient backup power to keep your equipment running during power outages or fluctuations. The UPS features a 220VAC input voltage and provides a stable 230VAC ± 10% output voltage.
