Lightwave 3000VA UPS Features and Description

Product Overview

Lightwave 3000VA UPS is efficient and durable, this UPS features a Boost and buck AVR, with LED indicators for easy monitoring and it is fully digitized microprocessor controlled.

Lightwave UPSs are systematically and carefully engineered to offer discerning customers enhanced power availability which is built on well tested and reliable technology.

It offers very high value to its diverse customers in different applications

General Specifications

• Cold-start capable
• Green mode
• High online efficiency
• LCD Status Display
• Pure sine wave output on battery
• Temperature-compensated battery charging
• Typical recharge time: 3hour(s)
• Capacity: 3000va
• Output power capacity: 1.3 KWatts / 2.0 kVA
• Max Confidurable Power: 1.3 KWatts / 2.0 kVA
• Nominal Output Voltage: 230V
• Output Voltage Distortion: Less than 5% at full load.
• Output Frequency (sync to mains): 50 Hz
• Topology: Line Interactive
• Waveform Type: Sine Wave
• Output Connections: (6) IEC 320 C13 (Battery Backup), (1) IEC 320 C19 (Battery Backup)
• Nominal Input Voltage: 230V
• Input Frequency: 47 – 63 Hz
• Input Connections: IEC-320 C20
• Input Voltage range for main operations: 180 – 287V
• Input voltage adjustable range for mains operation: 170 – 300V
• Other Input Voltages: 220, 240
• Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
• Typical recharge time: 3hour(s)
• Expected Battery Life (years): 3 – 5
• Interface Port(s): USB

Lightwave 3000VA UPS is available at Infinite Solutions. Visit us and enjoy our discounted prices.
